gigabyte Płyta główna B550M DS3H AM4 4DDR4 HDMI/DVI M.2 USB3.2 mATX

Format:micro ATX; Chipset:AMD B550, AMD; Socket:Socket AM4; Motherboard memory module type:DDR4; RAID support:1, 10; PCI express 16x:2; COM portB550M DS3HAMD B550 Ultra Durable Motherboard with Pure Digital VRM Solution, PCIe 4.0 x16 Slot, Dual PCIe 4.0/3.0 M.2 Connectors, Realtek GbE LAN, Smart Fan 6 with FAN STOP, RGB FUSION 2.0, Q-Flash PlusSupports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series ProcessorsDual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs6+2 Phases Pure Digital VRM Solution with Low RDS(on) MOSFETsUltra Durable™ PCIe 4.0 Ready x16 SlotDual Ultra-Fast NVMe PCIe 4.0/3.0 M.2 ConnectorsHigh Quality Audio Capacitors and Audio Noise Guard for Ultimate Audio QualityRealtek GbE LAN with Bandwidth ManagementRear HDMI, DVI, and DisplayPort SupportRGB FUSION 2.0 Supports Addressable LED & RGB LED StripsSmart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOPQ-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics CardAnti-Sulfur Resistors DesignThis MB has several revisions, you can see the differences in the belowCPUAMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 and Ryzen™ 3000 G-Series ProcessorsSocket AM4(Please refer qqq1qqq1CPU Support Listqqq1qqq1 for more information.)ChipsetAMD B550Memory4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memorySupport for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MT/s memory modulesDual channel memory architectureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modulesSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules(Please refer qqq1qqq1Memory Support Listqqq1qqq1 for more information.)Onboard GraphicsPCB Rev. 1.7, 1.5Integrated Graphics Processor:- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz* The DVI-D port does not support D-Sub connection by adapter.- 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR.Support for up to 3 displays at the same timeMaximum shared memory of 16 GBPCB Rev. 1.4, 1.3, 1.2, 1.1, 1.0Integrated Graphics Processor:1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz* The DVI-D port does not support D-Sub connection by adapter.1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR.Maximum shared memory of 16 GBAudioPCB Rev. 1.7Realtek ALC1220-VB CODEC* The back panel line out jack supports DSD audio.High Definition Audio2/4/5.1/7.1-channel* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.PCB Rev. 1.5, 1.4, 1.3, 1.2, 1.1, 1.0Realtek Audio CODECHigh Definition Audio2/4/5.1/7.1-channelSupport for S/PDIF Out* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.LANPCB Rev. 1.7, 1.3, 1.2, 1.1, 1.0Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)PCB Rev. 1.5, 1.4Realtek GbE LAN chip (1 Gbps/100 Mbps)Expansion Slots1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:- AMD Ryzen™ 5000 Series*/3000 Series Processors support PCIe 4.0 x16 mode* Actual support may vary by AMD CPUqqq1s specification.- AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support PCIe 3.0x16 mode* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:- Supporting PCIe 3.0 x4 mode1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset:- Supporting PCIe 3.0 x1 modeStorage InterfacePCB Rev. 1.7, 1.51 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280/22110 SSDs:- AMD Ryzen™ 5000 Series/3000 Series Processors support SATA and PCIe 4.0x4/x2 SSDs- AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SSDs:- Supporting SATA and PCIe 3.0 x2 SSDs4 x SATA 6Gb/s connectors, integrated in the ChipsetSupport for RAID 0, RAID 1, and RAID 10PCB Rev. 1.4, 1.3, 1.2, 1.1, 1.01 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:AMD Ryzen™ 5000 Series and Ryzen™ 3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDsAMD Ryzen™ Ryzen™ 5000 G-Series and Ryzen™ 4000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280 SSDs:Supporting SATA and PCIe 3.0 x2 SSDs4 x SATA 6Gb/s connectors, integrated in the Chipset:Support for RAID 0, RAID 1, and RAID 10USBCPU:- 4 x USB 3.2 Gen 1 ports on the back panelChipset:- 2 x USB 3.2 Gen 1 ports available through the internal USB header- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)Internal I/O ConnectorsPCB Rev. 1.71 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header2 x system fan headers2 x addressable LED strip headers2 x RGB LED strip headers1 x CPU cooler LED strip/RGB LED strip header2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB 3.2 Gen 1 header1 x USB 2.0/1.1 header1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)1 x serial port header1 x Clear CMOS jumper1 x Q-Flash Plus buttonPCB Rev. 1.51 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header2 x system fan headers2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB 3.2 Gen 1 header1 x USB 2.0/1.1 header1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)1 x Clear CMOS jumperPCB Rev. 1.4, 1.3, 1.2, 1.1, 1.01 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header2 x system fan headers2 x addressable LED strip headers2 x RGB LED strip headers1 x CPU cooler LED strip/RGB LED strip header2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB 3.2 Gen 1 header1 x USB 2.0/1.1 header1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)1 x serial port header1 x Clear CMOS jumper1 x Q-Flash Plus button*All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W.Back Panel ConnectorsPCB Rev. 1.7, 1.51 x PS/2 keyboard/mouse port1 x DVI-D port1 x DisplayPort1 x HDMI port4 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacksPCB Rev. 1.4, 1.3, 1.2, 1.1, 1.01 x PS/2 keyboard/mouse port1 x DVI-D port1 x HDMI port4 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacksI/O ControlleriTE I/O Controller ChipH/W MonitoringVoltage detectionTemperature detectionFan speed detectionOverheating warningFan fail warningFan speed control* Whether the fan speed control function is supported will depend on the cooler you install.BIOS1 x 128 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Unique FeaturesSupport for APP Center* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.@BIOSEasyTuneRGB FusionSmart BackupSystem Information ViewerSupport for Q-Flash PlusSupport for Q-FlashSupport for Xpress InstallBundled SoftwareNorton Internet Security (OEM version)LAN bandwidth management softwareOperating SystemSupport for Windows 11 64-bitSupport for Windows 10 64-bitForm FactorMicro ATX Form Factor; 24.4cm x 24.4cm

Budowa: µATX
Chipset: AMD B550
VRM: 7 rzeczywistych faz (5+3), kontroler PWM: RAA229004 (max. 8 faz)
MOSFETs CPU: 5x 46A 4C10N/?10x 4C06N
MOSFETs SoC: 3x 46A 4C10N/?4C06N
RAM: 4x DDR4 DIMM, dual PC4-37866U/?DDR4-4733 (OC), max. 128GB (UDIMM)
Sloty rozszerzeń: 1x PCIe 4.0 x16, 1x PCIe 3.0 x16 (x4), 1x PCIe 3.0 x1, 1x M.2/?M-Key (PCIe 4.0 x4/?SATA, 22110/?2280/?2260/?2242), 1x M.2/?M-Key (PCIe 3.0 x2/?SATA, 2280/?2260/?2242)
Złącza zewnętrzne: 1 x DVI-D (iGPU), 1x HDMI 2.1 (iGPU), 4x USB-A 3.0, 4x USB-A 2.0, 1x Gb LAN (Realtek RTL8118AS), 3x wtyczka jack, 1x combo PS/?2
Złącza wewnętrzne: 1x USB 3.0 Header (2x USB 3.0), 1x USB 2.0 Header (2x USB 2.0), 4x SATA 6Gb/s (B550), 1x port szeregowy, 1x TPM-Header
Header Chłodzenie: 1x Wentylatory CPU 4-Pin, 2x wentylator 4-Pin
Header Oświetlenie: 3x 4-Pin RGB (+12V/?G/?R/?B, max. 2A), 2x 3-Pin ARGB (+5V/?DATA/?GND, max. 5A)
Przyciski/przełączniki: USB BIOS Flashback/?Q-Flash Plus (wewn.)
Audio: 7.1 (Realtek ALC887)
Onboard-Grafika: iGPU
Wireless: brak
Poziom RAID: 0/?1/?10 (B550)
Multi GPU: brak
Złącza zasilania: 1x 24-Pin ATX, 1x 8-Pin EPS12V
Oświetlenie: brak
BIOS: 1x 32MB (256Mb)
Cechy dodatkowe: Audio+solid capacitors


Budowa: µATX
Chipset: AMD B550
VRM: 7 rzeczywistych faz (5+3), kontroler PWM: RAA229004 (max. 8 faz)
MOSFETs CPU: 5x 46A 4C10N/?10x 4C06N
MOSFETs SoC: 3x 46A 4C10N/?4C06N
RAM: 4x DDR4 DIMM, dual PC4-37866U/?DDR4-4733 (OC), max. 128GB (UDIMM)
Sloty rozszerzeń: 1x PCIe 4.0 x16, 1x PCIe 3.0 x16 (x4), 1x PCIe 3.0 x1, 1x M.2/?M-Key (PCIe 4.0 x4/?SATA, 22110/?2280/?2260/?2242), 1x M.2/?M-Key (PCIe 3.0 x2/?SATA, 2280/?2260/?2242)
Złącza zewnętrzne: 1 x DVI-D (iGPU), 1x HDMI 2.1 (iGPU), 4x USB-A 3.0, 4x USB-A 2.0, 1x Gb LAN (Realtek RTL8118AS), 3x wtyczka jack, 1x combo PS/?2
Złącza wewnętrzne: 1x USB 3.0 Header (2x USB 3.0), 1x USB 2.0 Header (2x USB 2.0), 4x SATA 6Gb/s (B550), 1x port szeregowy, 1x TPM-Header
Header Chłodzenie: 1x Wentylatory CPU 4-Pin, 2x wentylator 4-Pin
Header Oświetlenie: 3x 4-Pin RGB (+12V/?G/?R/?B, max. 2A), 2x 3-Pin ARGB (+5V/?DATA/?GND, max. 5A)
Przyciski/przełączniki: USB BIOS Flashback/?Q-Flash Plus (wewn.)
Audio: 7.1 (Realtek ALC887)
Onboard-Grafika: iGPU
Wireless: brak
Poziom RAID: 0/?1/?10 (B550)
Multi GPU: brak
Złącza zasilania: 1x 24-Pin ATX, 1x 8-Pin EPS12V
Oświetlenie: brak
BIOS: 1x 32MB (256Mb)
Cechy dodatkowe: Audio+solid capacitors


Gigabyte B550MDS3H. Producent procesora: AMD, Gniazdo procesora: Socket AM4, Procesor: 3rd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 7, 3rd.... Obsługiwane rodzaje pamięci: DDR4-SDRAM, Maksymalna pojemność pamięci: 128 GB, Typ slotów pamięci: DIMM. Wspierane interfejsy dysków twardych: SATA III, Obsługiwane rodzaje dysków: HDD & SSD, Poziomy raid: 0, 1, 10. Pamięć karty graficznej podsystemu graficznego: 16000 MB, Maks. rozdzielczość: 4096 x 2160 px. Rodzaj interfejsu sieci Ethernet: Gigabit Ethernet
